Main Technical Parameters | |||||
Machine model |
ZPCI-S-600 |
ZPCI-S-800 |
ZPCI-S-1000 |
ZPCI-S-1200 |
ZPCI-S-1600mm |
Max. material width |
600mm |
800mm |
1000mm |
1200mm |
1600mm |
Max. printing width |
550mm |
750mm |
950mm |
1150mm |
1550mm |
Suitable for material |
Paper |
||||
Colors |
4 color/6 color/8 color |
||||
Printing length |
320-860mm |
||||
Drive type |
Gearless full servo drive |
||||
Machine speed |
50-550m/min |
||||
Printing speed |
50-500m/min(Depends on printed material) |
||||
Printing precision |
+-0.075mm |
||||
Max. material dia |
Ф800mm |
||||
Voltage |
3P 380V |
Product Features:
1. The unwinding adopts a duplex rotary frame, which automatically accepts and changes materials without stopping the machine; Automatic alarm when the working shaft coil reaches the set diameter.
2. The entire machine is driven by high-precision servo motors, without the need for any gears, resulting in a quieter, smoother, and more precise operation.
3. The printing unit adopts ceramic mesh rollers for ink transfer, a bi-directional closed ink scraping method, and the ink pump automatically supplies ink;
4. Adopting an automatic registration system, the color accuracy is high and the setting time is short, reducing waste and improving production capacity.
5. Friction winding is used for winding, and the material is automatically received without stopping the machine.
6. Independent drying system, using the electric heating method, adjustable temperature, and variable frequency motor to adjust the air intake system.
