Motor model | Specs | Output Power W |
Voltage V |
Frequency Hz |
Current A |
Starting Torque | Rated Torque | Rated Revolution r/min |
Capacity/Ve μ F/VAC |
||
JWD types | mN.m | gf. cm | mN.m | gf. cm | |||||||
6IK200GU-CF 6IK200A-CF |
Induction | 200 | 1-phase 220 |
50 | 1.55 | 1485 | 14850 | 1414 | 14140 | 1350 | 8/450 |
60 | 1.5 | 1294 | 12940 | 1232 | 12320 | 1550 | 8/450 | ||||
6RK200GU-CF 6RK200A-CF |
Reversible | 50 | 1.55 | 1485 | 14850 | 1414 | 14140 | 1350 | 10/450 | ||
60 | 1.5 | 1294 | 12940 | 1232 | 12320 | 1550 | 10/450 | ||||
6IK200GU-AF 6IK200A-AF |
Induction | 200 | 1-phase 110 |
50 | 3.0 | 1485 | 14850 | 1414 | 14140 | 1350 | 32/250 |
60 | 2.8 | 1294 | 12940 | 1232 | 12320 | 1550 | 30/250 | ||||
6RK200GU-AF 6RK200A-AF |
Reversible | 50 | 3.0 | 1485 | 14850 | 1414 | 14140 | 1350 | 40/250 | ||
60 | 2.8 | 1294 | 12940 | 1232 | 12320 | 1550 | 36/250 | ||||
6IK200GU-UF 6IK200A-UF |
200 | 3-phase 380 |
50 | 0.9 | 1600 | 16000 | 1450 | 14500 | 1350 | ||
60 | 0.87 | 1386 | 13860 | 1260 | 12600 | 1550 | |||||
6RK200GU-SF 6RK200A-SF |
200 | 3-phase 220 |
50 | 1.15 | 1600 | 16000 | 1450 | 14500 | 1350 | ||
60 | 1.1 | 1386 | 13860 | 1260 | 12600 | 1550 | |||||
6IK250GU-CF 6IK250A-CF |
Induction | 250 | 1-phase 220 |
50 | 1.6 | 2020 | 20200 | 1837 | 18370 | 1350 | 10/450 |
60 | 1.55 | 1700 | 17000 | 1540 | 15400 | 1550 | 10/450 | ||||
6RK250GU-CF 6RK250A-CF |
Reversible | 50 | 1.6 | 2020 | 20200 | 1837 | 18370 | 1350 | 12/450 | ||
60 | 1.55 | 1700 | 17000 | 1540 | 15400 | 1550 | 12/450 | ||||
6IK250GU-AF 6IK250A-AF |
Induction | 250 | 1-phase 110 |
50 | 3.2 | 2020 | 20200 | 1837 | 18370 | 1350 | 40/250 |
60 | 3.0 | 1700 | 17000 | 1540 | 15400 | 1550 | 40/250 | ||||
6RK250GU-AF 6RK250A-AF |
Reversible | 50 | 3.3 | 2020 | 20200 | 1837 | 18370 | 1350 | 48/250 | ||
60 | 3.2 | 1700 | 17000 | 1540 | 15400 | 1550 | 48/250 | ||||
6RK250GU-UF 6RK250A-UF |
250 | 3-phase 380 |
50 | 1.3 | 2022 | 20220 | 1840 | 18400 | 1350 | ||
60 | 1.2 | 1760 | 17600 | 1600 | 16000 | 1550 | |||||
6RK250GU-SF 6RK250A-SF |
250 | 3-phase 220 |
50 | 1.21 | 2022 | 20220 | 1840 | 18400 | 1350 | ||
60 | 1.15 | 1760 | 17600 | 1600 | 16000 | 1550 |
●Parameters in the above table refer to the motor alone, without any load device.
●Permissible change in rated speed and rated current of the motor is within the range of士5%.
Geared-down parameter |
Synchronous speed | 500 | 300 | 200 | 150 | 120 | 100 | 85 | 75 | 60 | 50 | 40 | 37 | 30 | 25 | 20 | 15 | 12 | 10 | 8 | 7 | 6 | |
ratio | 3 | 5 | 7.5 | 10 | 12.5 | 15 | 18 | 20 | 25 | 30 | 36 | 40 | 50 | 60 | 75 | 100 | 120 | 150 | 180 | 200 | 250 | ||
Max allowable load |
200W | kg. cm N.m |
39.4 3.86 |
66 6.44 |
89.8 8.8 |
119 11.7 |
149 14.5 |
180 17.6 |
214 21.0 |
239 23.4 |
299 29.3 |
358 35.1 |
392 38.4 |
435 42.6 |
440 43 |
||||||||
250W | kg. cm N.m |
49.3 4.83 |
82.1 8.1 |
112 11 |
149 14.6 |
486 18.3 |
224 22 |
268 26.4 |
298 29.3 |
375 36.6 |
438 43 |
440 43 |
●The speed is based on the synchronous motor speed reduction ratio as a benchmark calculated by dividing the value. Actual speed will vary as the size of the load changes in less than the values shown in 2~15%.
●Hope the table of the reduction ratio is greater than the further reduction, it would be installed between the motor and the reducer reduction ratio of 10 in the middle of the reducer.
●When the load torque exceeds the maximum allowable load torque gear motor, and a locked rotor situation exists, please slow down the box at the junction of the output shaft and load torque limit device installed to ensure the normal operation gearbox.
